Overview Ideal for educational, commercial office or multi-dwelling residential settings, these stylish, durable locks, leveraging proven Networx access control technology, offer a choice of ID credential technology, and can be used to control access a door at a time; across a wireless network; or as an integral part of a new or existing enterprise security system—spanning a few, or thousands of doors, in one building, a campus or multiple sites around the world.
Take a Video Tour and See What All of the ArchiTech Platform Can Do for You
Downloadable Resources
ArchiTech Series Spec Sheet ALA505D Article as appeared in July 2014 Locksmith Ledger ArchiTech Mobile Access A681
• All Applications and Doors - Cylindrical and Mortise models for wood and metal doors, for new and existing applications, with wireless surface mount or mortised-in electronics and batteries • Customize To Match Any Aesthetic Look, For Every Décor - Durable ANSI/BHMA Grade 1 hardware in over 300 locks, levers, roses and finishes • Future-Proof Multi-Technology Access ID Credentials Replace Cumbersome Keys – HID® Prox, Mag Stripe, Smart Cards, PIV, keyfobs and remote buttons • Emergency Lock-Down option via lock, button, keyfob or server (where networked). (Global Unlock via server too.) • Automatic-Deadbolt option for automatic keyless
 locking of deadbolt upon exiting (ANSI F20 Function) • Proven, Low Maintenance, Wireless Installation And Unsurpassed Battery-Life with Advanced Power-Saver circuit, with years of use in even high-traffic areas, using off-the-shelf AA batteries
Choice of mortised-in electronics (top) or surface mount models (below).
• Flexible System Programming Locally using a USB Gateway or remotely across a wireless network (using free Alarm Lock DL-WINDOWS Windows based software) or integrated on an enterprise class IT environment, in realtime, using either Continental Access CA4K® or Lenel OnGuard® • Networking Choices – Choose 802.11 or Ethernet network, with wireless encrypted bi-directional gateways, in which many locks communicate to a single gateway, or use a wireless RF USB Gateway equivalent. For entry door applications and the like, used in conjunction with strikes and mags, use with Networx NetPanels. Or, use as a single-door control, as part of the IT-Network environment, with CA4K or OnGuard, as above
